C9300-24S-E Cisco Catalyst 9300 24-port modular uplinks 1G SFP Switch Network Essentials

Key Attributes:

Model No.: C9300-24S-E
Brand Name: CISCO
Condition: Original, New in box
Warranty: 1 Year
MOQ: 1 Piece
Payment Terms: T/T
Shipping Terms: DHL,FedEx,UPS,Aramex,Air Cargo
Lead Time: 2-3 working days
Price: Negotiable

Product Details

* 100% Original New *   C9300-24S-E:  Cisco Catalyst 9300 24-port modular uplinks 1G SFP Switch, Network Essentials



The Cisco C9300-24S-E is a stackable enterprise switch designed to maximize performance, security, and cloud-readiness for modern enterprise networks. As a flagship Cisco Catalyst solution, it is engineered for mission-critical deployments, delivering powerful switching efficiency and robust feature sets. The stackable enterprise position of the C9300-24S-E allows companies to scale easily, optimize workloads, and streamline network expansion while maintaining a consistent security posture. At its core, the switch integrates advanced security capabilities to safeguard critical assets, offers seamless cloud integration to support agile deployment models, and provides a future-ready architecture guaranteeing easy adaptations to shifting connectivity demands. The architecture excels at high-throughput link aggregation, rapid failover, and virtualization—key for distributed, high-density campus and edge environments. Enterprises leveraging the C9300-24S-E benefit from flexible modular uplinks, enhanced Layer 3 routing, extensive VLAN support, and high MTBF for continuous operation. Cloud-managed features ensure simplified provisioning and monitoring, all while maintaining robust security compliance. In summary, the C9300-24S-E delivers the reliability, scalability, and performance expected from the Cisco Catalyst line, adapting fluidly to the evolving needs of global organizations in a secure, cloud-enabled environment.





Specification




C9300-24S-E Specification
Model C9300-24S-E
Brand Cisco
Total 10/100/1000 or Multigigabit copper ports 24x 1G SFP
Uplink Configuration Modular Uplinks
Default AC power supply 715W AC
Available PoE power N/A
Dimensions (H x W x D) 1.73 x 17.5 x 17.7 Inches
Cisco StackWise-480 Yes
Cisco StackPower Yes
Default power supply PWR-C1-715WAC-P/2
Switching capacity 208 Gbps
Stacking bandwidth 688 Gbps
Forwarding rate 154.76 Mpps
Total number of MAC addresses 32000
Total number of IPv4 routes (ARP plus learned routes) 32,000 (24,000 direct routes and 8000 indirect routes)
IPv4 routing entries 32000
DRAM 8 GB
Flash 16 GB
VLAN IDs 4094
Wireless bandwidth per switch Up to 96 Gbps on 48-port Gigabit Ethernet model
Environmental Reduction of Hazardous Substances (ROHS) 5







Related Products




Cisco Catalyst 9300 Series Switches
C9300-24T-E  C9300-48T-E   C9300-24UX-E
C9300-24T-A  C9300-48T-A   C9300-24UB-A
C9300-24P-E   C9300-48P-E   C9300-24UX-E
C9300-24P-A   C9300-48P-A   C9300-24UX-A
C9300-24U-E   C9300-48U-E   C9300-24UXB-E
C9300-24U-A   C9300-48U-A   C9300-24UXB-A
C9300-24S-E   C9300-48S-E   C9300-48UXM-E
C9300-24S-A   C9300-48S-A   C9300-48UXM-A
C9300L-24T-4G-E   C9300L-24T-4X-E   C9300-48UN-E
C9300L-24T-4G-A   C9300L-24T-4X-A   C9300-48UN-A
C9300L-24P-4G-E   C9300L-24P-4X-E   C9300-48UB-E
C9300L-24P-4G-A   C9300L-24P-4X-A   C9300-48UB-A
C9300L-48T-4G-E   C9300L-48T-4X-E   C9300X-12Y-E
C9300L-48T-4G-A   C9300L-48T-4X-A   C9300X-12Y-A
C9300L-48P-4G-E   C9300L-48P-4X-E   C9300X-24Y-E
C9300L-48P-4G-A   C9300L-48P-4X-A   C9300X-24Y-A
C9300X-12Y-E C9300X-24HX-E C9300X-48TX-E
C9300X-12Y-A C9300X-24HX-A C9300X-48TX-A
C9300X-12Y-M C9300X-24HX-M C9300X-48TX-M
C9300X-24Y-E C9300X-48HX-E C9300X-48HXN-E
C9300X-24Y-A C9300X-48HX-A C9300X-48HXN-A
C9300X-24Y-M C9300X-48HX-M C9300X-48HXN-M

Cisco Catalyst 9300 Series Switch Network Modules
C9300-NM-8X   C9300-NM-4G   C9300-NM-2Q
C9300-NM-2Y   C9300-NM-4M

StackWise-320 Accessories
C9300L-STACK-KIT







FAQ




Q: Is your product original?
A: Yes, our product is original, we only sells original product.



Q: How to pay?
A: You can pay by T/T,Western Union,MoneyGram.



Q: How do you guarantee delivery after payment?
A: We will send all products usually within 3 working days after payment confirmed, we want to do long-term business with every customer, not one time business, so we really need your trust. Work with us, your money is safe, your order is safe.



Q: How long is the warranty?
A: We can provide 1 year warranty, so please don't worry to cooperate with us, you have good guarantee.



Q: If the product has quality problem, how to solve it?
A:  If there is quality problem during warranty, you can ship back to get replacement or refund.



Q:  How to ship the product to me?
A:  We can ship to worldwide by express logistics, such as DHL,FedEx,UPS,Aramex,Air Cargo, it usually takes 3-5 days to destination.
