WS-C3850-12XS-S Cisco Catalyst 3850 12 Port 10G Fiber Switch IP Base
Model No.: WS-C3850-12XS-S
Brand Name: CISCO
Condition: Original, New in box
Warranty: 1 Year
MOQ: 1 Piece
Payment Terms: T/T
Shipping Terms: DHL,FedEx,UPS,Aramex,Air Cargo
Lead Time: 2-3 working days
Price: Negotiable
* 100% Original New * WS-C3850-12XS-S: Cisco Catalyst 3850 12 Port 10G Fiber Switch IP Base
The Cisco WS-C3850-12XS-S is an enterprise-class Catalyst switch designed for high-density 10G aggregation and core applications. This 1U rack-mountable switch delivers 320Gbps switching capacity and 227.28Mpps forwarding performance across 12 SFP+ ports, ideal for data-intensive enterprise networks. With StackWise stacking up to nine units and 480Gbps stack bandwidth, it simplifies scaling for mid-to-large offices and regional data centers. Integrated wireless controller capabilities support up to 100 access points and 2,000 clients per stack.
Specification
| WS-C3850-12XS-S Specification | |
| Model | WS-C3850-12XS-S |
| Brand | Cisco |
| Enclosure Type | Rack-mountable - 1U |
| Ports | 12 x SFP+ ports |
| Network Management Interface | Ethernet management port: RJ-45 connectors, 4-pair Cat-5 UTP cabling; Management console port: RJ-45-to-DB9 cable for PC connections |
| Available PoE Power | None |
| Switching Capacity | 320Gbps |
| Maximum Stacking Number | 9 |
| Stack Bandwidth | 480Gbps |
| Forwarding Performance | 227.28Mpps |
| RAM | 4GB |
| Flash Memory | 4GB |
| Number of AP per Switch/Stack | 100 |
| Number of Wireless Clients per Switch/Stack | 2000 |
| Total Number of WLANs per Switch | 64 |
| Wireless Bandwidth per Switch | Up to 20Gbps |
| Network Module Options | C3850-NM-4-1G: 4 x 1G uplink network module C3850-NM-2-10G: 2 x 10G or 4 x 1G uplink network module |
| Stacking Cables | STACK-T1-50CM StackWise stacking cable (0.5 m) STACK-T1-1M StackWise stacking cable (1.0 m) STACK-T1-3M StackWise stacking cable (3.0 m) |
| Stack Power Cables (Recommended) | CAB-SPWR-30CM stack power cable (30cm) CAB-SPWR-150CM stack power cable (150cm) |
| Power Supply | PWR-C1-350WAC |
| Power Redundancy | Optional |
| Dimensions (W x D x H) | 44.5 x 45 x 4.45 cm |
| Rack Mounting Kit | Optional |
| System Software | IOS IP Base (upgradable) |
Related Products
| Cisco Catalyst 3850 Series Switches | |
| WS-C3850-48T-L | WS-C3850-24S-S |
| WS-C3850-48T-S | WS-C3850-24S-E |
| WS-C3850-48T-E | WS-C3850-24T-L |
| WS-C3850-48P-L | WS-C3850-24T-S |
| WS-C3850-48P-S | WS-C3850-24T-E |
| WS-C3850-48P-E | WS-C3850-24P-L |
| WS-C3850-48F-L | WS-C3850-24P-S |
| WS-C3850-48F-S | WS-C3850-24P-E |
| WS-C3850-48F-E | WS-C3850-24XS-S |
| WS-C3850-48XS-S | WS-C3850-24XS-E |
| WS-C3850-48XS-E | WS-C3850-12XS-S |
| WS-C3850-12XS-E | |
| Cisco Catalyst 3850 Series Switch Network Modules | |
| C3850-NM-4-1G | C3850-NM-4-10G |
| C3850-NM-2-10G | C3850-NM-8-10G |
| C3850-NM-2-40G | |
FAQ
Q: Is your product original?
A: Yes, our product is original, we only sells original product.
Q: How to pay?
A: You can pay by T/T,Western Union,MoneyGram.
Q: How do you guarantee delivery after payment?
A: We will send all products usually within 3 working days after payment confirmed, we want to do long-term business with every customer, not one time business, so we really need your trust. Work with us, your money is safe, your order is safe.
Q: How long is the warranty?
A: We can provide 1 year warranty, so please don't worry to cooperate with us, you have good guarantee.
Q: If the product has quality problem, how to solve it?
A: If there is quality problem during warranty, you can ship back to get replacement or refund.
Q: How to ship the product to me?
A: We can ship to worldwide by express logistics, such as DHL,FedEx,UPS,Aramex,Air Cargo, it usually takes 3-5 days to destination.
