S6730-H24X6C-V2, Huawei S6730-H-V2 Series Switch, 24x10GE SFP+,6x40GE QSFP28, No PS

Key Attributes:

Model No.: S6730-H24X6C-V2
Brand Name: CISCO
Condition: Original New
Warranty: 1 Year
MOQ: 1 Piece
Payment Terms: T/T
Shipping Terms: DHL,FedEx,UPS,Aramex,Air Cargo
Lead Time: 2-3 working days
Price: Negotiable

Product Details

* 100% Original New * S6730-H24X6C-V2: Huawei CloudEngine S6730-H24X6C-V2 (24*10GE SFP+ ports, 6*40GE QSFP28 ports, optional license for upgrade to 6*100GE QSFP28, without power module)

Huawei CloudEngine S6730-H-V2 series switches are next-generation enterprise-class core and aggregation switches that offer high performance, high reliability, cloud management, and intelligent operations and maintenance (O&M). They are purposebuilt with security, IoT, and cloud in mind. With these traits, CloudEngine S6730-H-V2 can be widely used in enterprise campuses, colleges/universities and other scenarios.

CloudEngine S6730-H-V2 switches offer 10GE, 40GE, and 100GE port types, flexibly adapting to diversified network bandwidth requirements. They also support cloud management and implement cloud-managed network services throughout the full lifecycle from planning, deployment, monitoring, experience visibility, and fault rectification, all the way to network optimization, greatly simplifying network management.

Specification

Huawei S6730-H24X6C-V2 Specification
Model	S6730-H24X6C-V2
Fixed ports	24 x 1/10 Gig SFP+, 6 x 40/100 Gig QSFP28
Dimensions (W x D x H)	43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.4 in. x 16.5 in.)
Chassis height(U)	1U
Chassis weight (including packaging)	8.9 Kg
Power supply type	• 600 W AC (pluggable) • 1000 W DC (pluggable）
Rated voltage range	• AC input (600 W AC ): 100 V AC to 240 V AC, 50/60 Hz • DC input (600 W AC ): 240 V DC • DC input (1000 W DC): -48 VDC to -60 V DC
Maximum voltage range	• AC input (600 W AC ): 90 V AC to 290 VAC, 45 Hz to 65 Hz • High-voltage DC input (600 W AC): 190 V DC to 290 V DC (meeting 240 V high voltage DC certification) • DC input (1000 W DC): -38.4 V DC to -72V DC
Maximum input current	• AC 600W：8A • DC 1000W：30A
Noise	• Under normal temperature (sound power): 65dB (A) • Under high temperature (sound power): 88dB (A) • Under normal temperature (sound pressure): 52dB (A)
Operating temperature	-5°C to +45°C (23°F to 113°F)
Storage temperature	-40°C to +70°C (-40°F to +158°F)
Relative humidity	5% to 95%, noncondensing
Power supply surge protection	• Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode • Using DC power modules: ±2 kV in differential mode, ±4 kV in common mode
Fans	4, Fan modules are pluggable
Heat dissipation	Heat dissipation with fan, intelligent fan speed adjustment

Related Products

Huawei CloudEngine S6730-H Series 10GE Switches
S6730-H24X6C	S6730-H48X6C

Huawei CloudEngine S6730-H-V2 Series 10GE Switches
S6730-H24X6C-V2	S6730-H28X6CZ-V2
S6730-H48X6C-V2	S6730-H28X6CZ-V2
S6730-H48X6CZ-V2	S6730-H28X6CZ-TV2
S6730-H48X6CZ-V2	S6730-H28X6CZ-TV2
S6730-H48X6CZ-TV2	S6730-H48X6C-TV2
S6730-H48X6CZ-TV2	S6730-H24X6C-TV2

Huawei CloudEngine S6730-S Series Switches
S6730-S24X6Q
