ET1BS12704E0, Huawei S12700E-4 Assembly Switch Chassis, 4 Slots, No Fan & PS
Model No.: ET1BS12704E0
Brand Name: CISCO
Condition: Original New
Warranty: 1 Year
MOQ: 1 Piece
Payment Terms: T/T
Shipping Terms: DHL,FedEx,UPS,Aramex,Air Cargo
Lead Time: 2-3 working days
Price: Negotiable
* 100% Original New * ET1BS12704E0: Huawei S12700E-4 Assembly Chassis
Introducing the Huawei S12700E-4 assembly chassis an advanced networking solution designed to meet the dynamic needs of modern businesses and data centers. The ET1BS12704E0 model is engineered to support complex applications and services, offering unparalleled performance, flexibility, and reliability. Ideal for enterprises looking to future-proof their network infrastructure. This chassis forms the backbone of a highly scalable and secure network environment.
Product Features
● High-density slot design for upscaling network capabilities
● Energy-efficient operation to reduce operational costs
● Enhanced security features for robust network protection
● Flexible networking options for diversified applications
● Support for advanced routing and switching protocols
Product Applications
● High-speed campus network backbone
● Data center network aggregation
● Cloud service provider infrastructure
Specification
| Huawei ET1BS12704E0 Specification | |
| Model | ET1BS12704E0 |
| Switching capacity | 19.2 Tbps |
| Forwarding performance* | 14,400 Mpps |
| MPU slots | 2 |
| SFU slots | 2 |
| LPU slots | 4 |
| Fan trays | 2 |
| Powe | 4 |
| Buffering capacity | Up to 200 ms data buffering per port |
| Redundancy design | MPU, SFU, power module, and fan module |
| Virtualization | CSS service port clustering |
| Dimensions (H x W x D) | 441.7*442*517.4, 10U |
| Weight (empty/fully configured) | 24.5kg/66kg Note • Empty configuration indicates that the switch has no line card, MPU, or power supply installed. Filler panels are used, instead. • Full configuration indicates that the switch is fully configured with MPUs, SFUs, line cards, and power supplies. Their maximum weights are used during calculation. |
| Operating voltage | DC：–48V～–60V AC：90V～290V |
| Maximum power consumption | 3344W |
| Operating temperature | • –60 m to +1800 m: 0°C to 45°C • 1800 m to 4000 m: The maximum operating temperature decreases by 1°C each time the altitude increases by 220 m. • 4000 m: 0°C to 35°C |
| Relative humidity | 5% to 95% (non-condensing) |
| Heat dissipation mode | Left-to-rear airflow, air-cooled heat dissipation, and intelligent fan speed adjustment |
Related Products
| Huawei CloudEngine S12700E Series Switches Basic Configuration | |
| LE2BN66ED000 | N66E DC assembly cabinet (eight 60A outputs, maximum 2200W, 600 × 600 × 2200 mm) |
| LE2BN66EA000 | N66E AC assembly cabinet (four 16 A outputs, a maximum of 2500W, 600 × 600 × 2200 mm) |
| ET1BS12704E0 | S12700E-4 Assembly Chassis |
| ET1BS12708E0 | S12700E-8 Assembly Chassis |
| ET1BS12712E1 | S12700E-12 Assembly Chassis |
| FAN-770A-B | Fan box (-5degC–55degC, 48V, 400W, 2, indoors, VA) |
| Main Processing Unit | |
| LST7MPUE0000 | S12700E Main Processing Unit E |
| LST7MPUE0001 | S12700E Main Processing Unit E |
| LST7MPUEC000 | S12700E Main Processing Unit EC |
| Monitoring Unit | |
| EH1D200CMU00 | Centralized Monitoring Unit |
| Power supply | |
| W2PSD2200 | 2200W DC power module |
| PAC3KS54-CE | 3000W AC power module (black) |
| PAC3KS54-NE | 3000W AC power module (black) |
