S5735-L24P4XE-A-V2, Huawei S5735-L PoE Switch, 24xGE RJ45, 4x10GE SFP+, PoE+, AC Power
Model No.: S5735-L24P4XE-A-V2
Brand Name: CISCO
Condition: Original New
Warranty: 1 Year
MOQ: 1 Piece
Payment Terms: T/T
Shipping Terms: DHL,FedEx,UPS,Aramex,Air Cargo
Lead Time: 2-3 working days
Price: Negotiable
* 100% Original New * S5735-L24P4XE-A-V2: Huawei CloudEngine S5735-L24P4XE-A-V2 (24*10/100/1000BASE-T ports, 4*10GE SFP+ ports, 2*stack ports, PoE+, AC power)
Specification
| Huawei S5735-L24P4XE-A-V2 Specification | |
| Model | S5735-L24P4XE-A-V2 |
| Fixed port | 24 x 10/100/1000Base T ports (PoE+), 4 x 10 GE SFP+ ports, 2 stack ports |
| Dimensions (H x W x D) | 43.6 mm x 442 mm x 220 mm |
| Chassis height | 1 U |
| Chassis weight (including packaging) | 3.81 kg |
| Power supply type | Built-in AC power |
| Rated voltage range | 100 V AC to 240 V AC, 50/60 Hz |
| Maximum voltage range | AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz |
| Maximum power consumption | • 55.4 W (without PD) • 460 W(with PD, PD Power consumption of :370W） • 496.08 W(with PD,PD Power consumption of :400W) |
| Noise | • Under normal temperature (sound power): 49.3dB (A) • Under high temperature (sound power): 63dB (A) • Under normal temperature (sound pressure): 37.3dB (A) |
| Long-term operating temperature | • 0-1800 m altitude: -5°C to +50°C • 1800-5000 m altitude: The operating temperature reduces by 1ºC every time the altitude increases by 220 m. |
| Storage temperature | -40°C to +70°C |
| Relative humidity | 5% to 95% (non condensing) |
| Surge protection specification (power port) | • Differential mode: ±6 kV • Common mode: ±6 kV |
| Heat dissipation | Air-cooled heat dissipation and intelligent speed adjustment |
| Physical security | One Kensington lock slot, can be used to lock the device to mounting bracket |
Related Products
| Huawei CloudEngine S5735-L-V2 Series Switches | |
| S5735-L8T4S-A-V2 | S5735-L24P4XE-A-V2 |
| S5735-L8P4S-A-V2 | S5735-L24P4XE-TA-V2 |
| S5735-L10T4X-A-V2 | S5735-L48T4S-A-V2 |
| S5735-L10T4X-TA-V2 | S5735-L48LP4S-A-V2 |
| S5735-L8P2T4X-A-V2 | S5735-L48T4XE-A-V2 |
| S5735-L8P2T4X-TA-V2 | S5735-L48T4XE-TA-V2 |
| S5735-L16T4S-A-V2 | S5735-L48T4XE-D-V2 |
| S5735-L24T4S-A-V2 | S5735-L48P4XE-A-V2 |
| S5735-L24P4S-A-V2 | S5735-L48LP4XE-A-V2 |
| S5735-L24T4XE-A-V2 | S5735-L24T8J4XE-A-V2 |
| S5735-L24T4XE-D-V2 | |
