S5735-L48P4X-A, Huawei S5735-L Switch, 48x10/100/1000BASE-T, 4x10 GE SFP+, PoE+, AC Power

Key Attributes:

Model No.: S5735-L48P4X-A
Brand Name: CISCO
Condition: Original New
Warranty: 1 Year
MOQ: 1 Piece
Payment Terms: T/T
Shipping Terms: DHL,FedEx,UPS,Aramex,Air Cargo
Lead Time: 2-3 working days
Price: Negotiable

Product Details

* 100% Original New * S5735-L48P4X-A: Huawei CloudEngine S5735-L48P4X-A bundle (48 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports, PoE+, 1*1000W PoE AC power module)

Huawei CloudEngine S5735-L series switches are ideal for scenarios such as enterprise campus network access and gigabit to the desktop. Built on next-generation, high-performance hardware and the Huawei Versatile Routing Platform (VRP), CloudEngine S5735-L switches stand out with compelling features such as intelligent stack (iStack), flexible Ethernet networking, and diversified security control. They support multiple Layer 3 routing protocols and provide high performance and service processing capabilities.

Specification

Huawei S5735-L48P4X-A Specification
Model	S5735-L48P4X-A
Fixed port	48 x 10/100/1000Base-T ports(PoE+), 4 x 10 GE SFP+ ports
Dimensions (H x W x D)	43.6 mm x 442 mm x 220 mm
Chassis height	1 U
Chassis weight (including packaging)	8.7 kg
Power supply type	• 600 W PoE AC (pluggable) • 1000 W PoE AC (pluggable) • 1000 W PoE DC (pluggable)
Rated voltage range	• AC input(600 /1000W AC PoE): 100 V AC to 130 V AC, 200 V AC to 240 V AC, 50/60 Hz • High-Voltage DC input(600 /1000W AC PoE): 240 V DC • DC input(1000 W DC PoE): -48 V DC to -60 V DC
Maximum voltage range	• AC input(600 /1000W AC PoE): 90 V AC to 290 V AC, 45 Hz to 65 Hz • High-Voltage DC input(600 /1000W AC PoE): 190 V DC to 290 V DC • DC input(1000 W DC PoE): -38.4 V DC to -72 V DC
Maximum power consumption	• 80 W (without PD) • 914 W (with PD, PD power consumption of 870 W)
Noise	58.9dB (A)
Long-term operating temperature	• 0-1800 m altitude: -5°C to +50°C • 1800-5000 m altitude: The operating temperature reduces by 1ºC every time the altitude increases by 220 m.
Short-term operating temperature	• 0-1800 m altitude: -5°C to +55°C • 1800-5000 m altitude: The operating temperature reduces by 1ºC every time the altitude increases by 220 m.
Storage temperature	-40°C to +70°C
Relative humidity	5% to 95% (non condensing)
Surge protection specification (service port)	±7 kV in common mode
Surge protection specification (power port)	• Differential mode: ± 6 kV • Common mode: ±6 kV
Heat dissipation	Air-cooled heat dissipation and intelligent speed adjustment
Physical security	One Kensington lock slot, can be used to lock the device to mounting bracket
